Selected Sensor Circuits: From Data Sheet to Simulation - Paperback

by Peter Baumann (Author)

This book shows the steps from data sheets of sensors to the extraction of model parameters for the program PSPICE in order to realize circuit analyses. Physical ENTITIES as temperature, humidity, light, pressure and sound are included by equations. The simulation concerns temperature displays, characteristics of humidity-sensors, light-to-voltage Converters, strain gauges, reed relays and Piezol-electric-sounders US-Converters and SAW Components

Back Jacket

This book shows the steps from data sheets of sensors to the extraction of model parameters for the program PSPICE in order to realize circuit analyses. Physical ENTITIES as temperature, humidity, light, pressure and sound are included by equations. The simulation concerns temperature displays, characteristics of humidity-sensors, light-to-voltage Converters, strain gauges, reed relays and Piezol-electric-sounders US-Converters and SAW Components

The Content

• NTC- and PTC-Sensors
• Band Gap Reference
• Humidity-Sensors
• RGB-Colour-Sensors
• light barreer
• force sensing resistor
• Hall-Sensor
• Piezoelectric sounder
• self-drive and external drive
• US-transmitter and -receiver
• SAW-Delay-Line

The Author

Prof. Dr.-Ing. habil. Peter Baumann - until 2019 was employed as a lecturer for sensor-circuits at Hochschule Bremen

This book is a translation of an original German edition. The translation was done with the help of artificial intelligence (machine translation by the service DeepL.com). A subsequent human revision was done primarily in terms of content, so that the book will read stylistically differently from a conventional translation.

Author Biography

Prof. Dr.-Ing. habil. Peter Baumann - until 2019 was employed as a lecturer for sensor-circuits at Hochschule Bremen.
